Parameters

• General Specifications

• Tunnel Size (W x H)

  800mm * 650mm

• Conveyor Speed

  0.20 m/sec

• Conveyor Load (Max. Load)

  180kg (Adequate distribution)

• Conveyor Height

  375mm

• Detector

  Dual-energy Detector

• View

  Single-view

• Supported Software

  ZKBio SIS

• Communication Interface

  RJ45(TCP/IP)

• Dimensions (L * W * H)

  2924mm * 1207mm *1500mm

• Console Dimensions (L * W * H)

  747mm * 706mm * 1279mm

• Package Dimensions (L * W * H)

  2200mm *1300mm * 1700mm

• Console Package Dimensions (L * W * H)

  890mm * 840mm * 1502mm

• Gross Weight (with Package)

  840kg+140kg (Console)

• Net Weight

  700kg+100kg (Console)

• Film Safety

  ASA/ISO1600

• Certifications

  CE-EMC, CE-MD, FCC sDOC

• X-ray Generator & Image Performance

• Anode Voltage

  80-160kV (adjustable)

• Tube Current

  0.3-1.0mA(adjustable)

• Wire Resolution

  36AWG

• Steel Penetration

  34mm

• Spatial Resolution

  HorizontalΦ1.3mm / VerticalΦ1.3mm

• Penetration Resolution

  32AWG

• Generator Cooling

  Sealed Oil Bath with Forced Air

• Beam Direction

  Vertically Upward

• X-ray Converter

  L-shaped Detector Line

• Computer

• Operating System

  Windows 10

• Processor

  i5-10500H

• RAM

  8GB

• Hard Drive

  1TB HDD

• Max Storage

  Up to 100,000 Scanned Images

• Monitor

  21.5″Color LED Screen (1920 x 1080P)

• Operating Environment

• System Power

  220 VAC +/- 10% 50/60Hz
  110 VAC +/- 10% 50/60Hz

• Power Consumption

  < 800W

• Noise Level

  < 58dB(A)

• Operating Temperature

  -10°C to +45°C

• Storage Temperature

  -20°C to +60°C

• Humidity

  5-95%, Non-condensing

• Health & Safety

• Radiation Leak Dosage

  < 0.5μSv/h (10cm From the Surface)
  Compliant with Radiation Safety Standards (< 5μSv/h ) for Cabinet X-ray Systems
