System

Main Processor

<!–{v.name}–>

Industrial-grade processor

Operating System

<!–{v.name}–>

Embedded Linux

Operating Interface

<!–{v.name}–>

Web; Local GUI

Perimeter Protection

Perimeter Performance AI by Recorder (Number of Channels)

<!–{v.name}–>

Advanced Mode: 2 channels, 10 IVS rules for each channel

General Mode: 4 channels, 10 IVS rules for each channel

Face Detection

Face Attributes

<!–{v.name}–>

6 attributes

Face Detection Performance of AI by Recorder (Number of Channels)

<!–{v.name}–>

2 channels (up to 8 face images/s each channel)

Face Recognition

Face Database Capacity

<!–{v.name}–>

Up to 10 face databases with 10,000 images.

Face Recognition Performance of AI by Recorder (Number of Channels)

<!–{v.name}–>

2 channels

SMD Plus

SMD Plus by Recorder

<!–{v.name}–>

8 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change

Audio and Video

Analog Camera Input

<!–{v.name}–>

8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

Camera Input

<!–{v.name}–>

1. CVI: 5 MP@25 fps; 5 MP@20 fps; 5 MP@10/12.5 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@50/60 fps; 720p@25/30 fps.

2. TVI: 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.

3. AHD: 5 MP@20 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.

IP Camera Input

<!–{v.name}–>

Up to 12 channels of IPC access

4 IP channels by default + 8 channels (analog channels are converted to IP channels)

Incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps

*After IP extension is enabled, the AI Function (IVS, SMD, FACE) will be disabled.

Encoding Capacity

<!–{v.name}–>

Encode Enhancement enabled：

Main stream:

4-ch 5 MP@(1 fps-12 fps)/5M-N@(1 fps-25 fps), others 5M-N@(1 fps-12 fps); 4-ch 4M-N/1080p@(1 fps-25 fps), others 4M-N@(1 fps-15 fps)/1080p@(1 fps-12 fps); 1080N/720p/960H/D1/CIF@(1 fps-25/30 fps)

Sub stream: D1/CIF@(1 fps-15 fps)

It changes to D1/CIF@(1 fps-7 fps) when Main stream is 5 MP/5M-N/4M-N/1080p.

*When Encode Enhancement is enabled, Face Recognition, Face Detection and Perimeter Protection cannot be used.

Encode Enhancement disabled：

Main stream:

5M-N@(1 fps –12 fps); 4M-N/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps)

Sub stream: D1/CIF@(1 fps–15 fps)

Dual-stream

<!–{v.name}–>

Yes

Video Bit Rate

<!–{v.name}–>

32 kbps–6144 kbps

Audio Sampling

<!–{v.name}–>

8 kHz, 16 bit

Audio Bit Rate

<!–{v.name}–>

64 kbps

Video Output

<!–{v.name}–>

1 HDMI, 1 VGA

HDMI: 2560 × 1440, 1920 × 1080, 1280 × 1024, 1280 × 720

VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

Multi-screen Display

<!–{v.name}–>

When IP extension mode not enabled: 1/4/8/9

When IP extension mode enabled: 1/4/8/9/16

Third-party Camera Access

<!–{v.name}–>

Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF

Compression Standard

Video Compression

<!–{v.name}–>

AI Coding; Smart H.265+; H.265; Smart H.264+; H.264

Audio Compression

<!–{v.name}–>

G.711a; G.711u; PCM

Network

Network Protocol

<!–{v.name}–>

HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

Mobile Phone Access

<!–{v.name}–>

iOS; Android

Interoperability

<!–{v.name}–>

ONVIF 23.12 (Profile T; Profile S; Profile G); CGI; SDK

Browser

<!–{v.name}–>

Chrome; IE; Safari; Edge; Firefox

Recording Playback

Record Mode

<!–{v.name}–>

General; alarm; motion detection; intelligent; POS

Recording Playback

<!–{v.name}–>

1/4/9

Backup Method

<!–{v.name}–>

USB device and network

Playback Mode

<!–{v.name}–>

Instant playback; general playback; event playback; tag playback; smart playback

Alarm

General Alarm

<!–{v.name}–>

Motion detection; alarm box; HDCVI alarm; camera external alarm; network alarm; PIR alarm

Anomaly Alarm

<!–{v.name}–>

Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline

Intelligent Alarm

<!–{v.name}–>

Face detection; face recognition; perimeter protection; SMD Plus

Alarm Linkage

<!–{v.name}–>

Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email

Ports

Audio Input

<!–{v.name}–>

1-channel RCA

8-channel BNC (Coaxial Audio)

Audio Output

<!–{v.name}–>

1-channel RCA

Two-way Talk

<!–{v.name}–>

Yes (share the same audio input with the first channel)

Disk Interface

<!–{v.name}–>

1 SATA port, up to 16 TB. This limit varies depending on the environment temperature.

RS-485

<!–{v.name}–>

1

USB

<!–{v.name}–>

2 (1 front USB 2.0 port, 1 rear USB 2.0 port)

HDMI

<!–{v.name}–>

1

VGA

<!–{v.name}–>

1

Network Port

<!–{v.name}–>

1 (10/100 Mbps Ethernet port, RJ-45)

General

Power Supply

<!–{v.name}–>

12 VDC, 2 A

Power Consumption

<!–{v.name}–>

<7 W (without HDD)

Net Weight

<!–{v.name}–>

0.97 kg (2.14 lb)

Gross Weight

<!–{v.name}–>

1.39 kg (3.07 lb)

Product Dimensions

<!–{v.name}–>

260.0 mm × 237.8 mm × 47.6 mm (10.24″ × 9.36″ × 1.87″) (W × D × H)

Packaging Dimensions

<!–{v.name}–>

344.0 mm × 89.0 mm × 287.0 mm (13.54″ × 3.50″ × 11.30″) (W × D × H)

Operating Temperature

<!–{v.name}–>

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Temperature

<!–{v.name}–>

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

<!–{v.name}–>

10%–90% (RH), non-condensing

Installation

<!–{v.name}–>

Desktop

Certifications

<!–{v.name}–>

CE-LVD: IEC 62368-1:2014

CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014
