System

Main Processor

<!–{v.name}–>

Industrial-grade processor

Operating System

<!–{v.name}–>

Embedded Linux

Operating Interface

<!–{v.name}–>

Web; Local GUI

SMD Plus

SMD Plus by Recorder

<!–{v.name}–>

8 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change

Audio and Video

Analog Camera Input

<!–{v.name}–>

16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

Camera Input

<!–{v.name}–>

1. CVI: 1080p@25/30 fps; 720p@25/30 fps.

2. TVI: 1080p@25/30 fps; 720p@25/30 fps.

3. AHD: 1080p@25/30 fps; 720p@25/30 fps.

IP Camera Input

<!–{v.name}–>

Up to 18 channels of IPC access

2 IP channels by default + 16 channels (analog channels are converted to IP channels)

Incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps

*After IP extension is enabled, the AI Function (SMD) will be disabled.

Encoding Capacity

<!–{v.name}–>

Main stream: the 1st channel 1080N/720p@(1 fps–25/30 fps), others 1080N/720p@(1 fps–15 fps); 960H/D1/CIF@(1 fps–25/30 fps)

Sub stream: CIF@(1 fps–7 fps)

Dual-stream

<!–{v.name}–>

Yes

Video Bit Rate

<!–{v.name}–>

32 kbps–4096 kbps

Audio Sampling

<!–{v.name}–>

8 kHz, 16 bit

Audio Bit Rate

<!–{v.name}–>

64 kbps

Video Output

<!–{v.name}–>

1 HDMI, 1 VGA

HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720

VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

Multi-screen Display

<!–{v.name}–>

When IP extension mode not enabled: 1/4/8/9/16

When IP extension mode enabled: 1/4/8/9/16/25

Third-party Camera Access

<!–{v.name}–>

Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF

Compression Standard

Video Compression

<!–{v.name}–>

AI Coding; Smart H.265+; H.265; Smart H.264+; H.264

Audio Compression

<!–{v.name}–>

G.711a; G.711u; PCM

Network

Network Protocol

<!–{v.name}–>

HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

Mobile Phone Access

<!–{v.name}–>

iOS; Android

Interoperability

<!–{v.name}–>

ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK

Browser

<!–{v.name}–>

Chrome; IE; Safari; Edge; Firefox

Recording Playback

Record Mode

<!–{v.name}–>

General; alarm; motion detection

Recording Playback

<!–{v.name}–>

1/4/9/16

Backup Method

<!–{v.name}–>

USB device and network

Playback Mode

<!–{v.name}–>

Instant playback; general playback; event playback; tag playback; smart playback

Alarm

General Alarm

<!–{v.name}–>

Motion detection; HDCVI alarm; camera external alarm; network alarm; PIR alarm

Anomaly Alarm

<!–{v.name}–>

Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline

Intelligent Alarm

<!–{v.name}–>

SMD Plus

Alarm Linkage

<!–{v.name}–>

Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email

Ports

Audio Input

<!–{v.name}–>

1-channel RCA

16-channel BNC (Coaxial Audio)

Audio Output

<!–{v.name}–>

1-channel RCA

Two-way Talk

<!–{v.name}–>

Yes (share the same audio input with the first channel)

Disk Interface

<!–{v.name}–>

1 SATA port, up to 16 TB. This limit varies depending on the environment temperature.

USB

<!–{v.name}–>

2 (2 rear USB 2.0 ports)

HDMI

<!–{v.name}–>

1

VGA

<!–{v.name}–>

1

Network Port

<!–{v.name}–>

1 (10/100 Mbps Ethernet port, RJ-45)

General

Power Supply

<!–{v.name}–>

12 VDC, 2 A

Power Consumption

<!–{v.name}–>

<10 W (without HDD)

Net Weight

<!–{v.name}–>

0.89 kg (1.96 lb)

Gross Weight

<!–{v.name}–>

1.42 kg (3.13 lb)

Product Dimensions

<!–{v.name}–>

260.0 mm × 229.6 mm × 47.6 mm (10.24″ × 9.04″ × 1.87″) (W × D × H)

Packaging Dimensions

<!–{v.name}–>

333.0 mm × 89.0 mm × 315.0 mm (13.11″ × 3.50″ × 12.40″) (W × D × H)

Operating Temperature

<!–{v.name}–>

–10 °C to +45 °C (+14 °F to +113 °F)

Storage Temperature

<!–{v.name}–>

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

<!–{v.name}–>

10%–90% (RH), non-condensing

Installation

<!–{v.name}–>

Desktop

Certifications

<!–{v.name}–>

CE-LVD: IEC 62368-1:2014

CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014

FCC: 47 CFR Part 15, Subpart B
