System

Main Processor

<!–{v.name}–>

Embedded Processor

Operating System

<!–{v.name}–>

Embedded Linux OS

Button Type

<!–{v.name}–>

Mechanical

Number of Buttons

<!–{v.name}–>

16

Basic

Screen Type

<!–{v.name}–>

Non-touchscreen

Display Screen

<!–{v.name}–>

2.3″OLED

Camera

<!–{v.name}–>

1/2.9″ 2 MP CMOS

Field of View

<!–{v.name}–>

H:140°,V:80°, D:160°

WDR

<!–{v.name}–>

120 dB

Noise Reduction

<!–{v.name}–>

3D NR

Video Compression

<!–{v.name}–>

H264，H265

Video Resolution

<!–{v.name}–>

Main stream: 720p,WVGA, D1, CIF

Sub stream: 1080p,WVGA, D1, QVGA, CIF

Video Frame Rate

<!–{v.name}–>

25 fps

Light Compensation

<!–{v.name}–>

Auto white light

Day/Night

<!–{v.name}–>

Color/B/W

Audio Compression

<!–{v.name}–>

G.711a, G.711u, PCM

Audio Input

<!–{v.name}–>

1

Audio Output

<!–{v.name}–>

Built-in Speaker

Audio Mode

<!–{v.name}–>

Two-way audio

Audio Enhancement

<!–{v.name}–>

Echo suppression/digital noise reduction

Audio Bit Rate

<!–{v.name}–>

16 KHz, 16 bit

Function

Communication Mode

<!–{v.name}–>

2-wire

Unlock Mode

<!–{v.name}–>

Card swiping;password;remote

Card Type

<!–{v.name}–>

Mifare card

Auto Snapshot

<!–{v.name}–>

Yes (SD card is inserted in the indoor monitor or door station)

Leave Videos

<!–{v.name}–>

NA;Yes (SD card is inserted in the indoor monitor or door station)

Storage

<!–{v.name}–>

Supports Micro SD card (up to 256 GB)

Web Configuration

<!–{v.name}–>

Yes

Performance

Card Reading Distance

<!–{v.name}–>

0 cm–3 cm (0″–1.18″)

Casing Material

<!–{v.name}–>

Aluminum

Capacity

Card Capacity

<!–{v.name}–>

10000

Port

RS-485

<!–{v.name}–>

1

Wiegand

<!–{v.name}–>

1

Alarm Input

<!–{v.name}–>

1

Alarm Output

<!–{v.name}–>

1

Power Output

<!–{v.name}–>

1 port,12 V/600 mA

Door Bell

<!–{v.name}–>

1

Exit Button

<!–{v.name}–>

1

Lock Control

<!–{v.name}–>

1

Network Port

<!–{v.name}–>

1 × RJ-45 port，10Mbps/100Mbps network port

Alarm

Tamper Alarm

<!–{v.name}–>

Yes

General

Appearance Color

<!–{v.name}–>

Silver

Power Supply

<!–{v.name}–>

48 VDC, 0.4 A, PoE (802.3af/at)

Power Adapter

<!–{v.name}–>

Optional

Installation

<!–{v.name}–>

Flush Mount;Surface Mount

Certifications

<!–{v.name}–>

CE

Accessory

<!–{v.name}–>

Flush mount box (optional);

Surface mount box (optional)

Product Dimensions

<!–{v.name}–>

200.0 mm × 98.0 mm × 35.4 mm (7.87″ × 3.86″ × 1.39″)

Protection

<!–{v.name}–>

IK08, IP65 (silicone sealant is needed, see the quick start guide)

Operating Temperature

<!–{v.name}–>

–40 °C to +60 °C (–40 °F to +140°F)

Operating Humidity

<!–{v.name}–>

10%–90% (RH), non-condensing

Operating Environment

<!–{v.name}–>

Outdoor

Operating Altitude

<!–{v.name}–>

Beneath 3000 m (9842.52 ft)

Power Consumption

<!–{v.name}–>

≤ 5 W (standby), ≤ 7 W (working)

Gross Weight

<!–{v.name}–>

657 g(1.45 lb)

Storage Temperature

<!–{v.name}–>

0 °C to +40 °C (+32 °F to +104 °F)

Storage Humidity

<!–{v.name}–>

30%–75%(RH)
