System

Main Processor

Embedded Processor

Operating System

Embedded Linux OS

Button Type

Mechanical

Network Protocol

UDP; TCP; IPv4; RTSP; SIP; P2P; RTP

Basic

Audio Compression

G.711a; G.711Mu; G.711u; PCM; MP3; G726

Audio Input

Built-in dual-way silicon microphone, external 3.5 mm audio input

Audio Output

Built-in dual speaker, external active speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression/digital noise reduction

Audio Bit Rate

16 KHz, 16 Bit

Function

Communication Mode

Full digital

Performance

Casing Material

Aluminum alloy

Port

RS-485

1

Alarm Input

2

Alarm Output

2

Power Output

2 (12 V/1 A;12 V/200 mA)

Network Port

2 × 10 M/100 M ports

Alarm

Tamper Alarm

Yes

General

Appearance Color

Silver

Power Supply

12 VDC, 3 A; Standard PoE

Power Adapter

Optional

Installation

Surface Mount

Certifications

CE

Accessory

Surface mount box (optional)

Product Dimensions

190.0 mm × 120.0 mm × 42.0 mm (7.5″ × 4.7″ × 1.7″)

Protection

IP65; IK10

Operating Temperature

–30 °C to +60 °C (-22 °F to +140 °F)

Operating Humidity

10%–90% (RH), non-condensing

Operating Environment

Outdoor
