SenseFace T1 & T2 is a time and attendance terminal which simplifies attendance solutions. It is aimed at small and medium-sized businesses (SMEs) that want to manage their workforce reliably and affordably.
SenseFace T1 & T2 offers flexible authentication options, such as facial authentication, fingerprint authentication, RFID authentication (optional) and password entry to suit different workplace preferences. SenseFace T1 & T2 supports Wi-Fi and compatible with ZKBio Zlink. This lets users manage employees and equipment, set attendance rules and check real-time attendance reports on their desktop or mobile device. Also, it has a 2,000mAh backup battery (optional) which provides a maximum of 2 hours of continuous operational power.
المواصفات الفنية (Parameters)
Parameters
-
Model
SenseFace T1
SenseFace T2 -
Display
2.4″ TFT Color LCD Screen (320*240)
-
Camera
WDR Binocular Camera @ 1MP
-
Operation System
Linux
-
Hardware
SenseFace T1: CPU: Dual-Core @ 1GHz; RAM: 512MB ROM: 8GB; Speaker: 8ohm @1W; Supplement Light: Yes/ Near-Infrared; Light*2; Physical Keypad: 16 Keys; Color: Black; Fingerprint Sensor: ZK Optical Sensor
SenseFace T2: CPU: Dual-Core @ 1GHz; RAM: 512MB ROM: 8GB; Speaker: 8ohm @1W; Supplement Light: Yes/ Near-Infrared; Light*2; Physical Keypad: 8 Keys; Color: Blue; Fingerprint Sensor: ZK Optical Sensor
-
Authentication method
Facial / Fingerprint / Card (Optional) / Password (Physical Keypad)
-
Face Template Capacity
1,500 (1:N) (Standard)
-
Fingerprint Template Capacity
1,500 (1:N) (Standard)
-
Card Capacity
3,000 (1:N) (Standard)
-
User Capacity
3,000 (1:N) (Standard)
-
Transaction Capacity
150,000
-
Max. User Password Length
8 digits
-
Biometric Authentication Speed
Less than 0.5 sec (Fingerprint), less than 0.35 sec (Facial Authentication)
-
False Acceptance Rate (FAR) %
FAR≤0.01% (Visible Light Facial Authentication), FAR ≤ 0.0001% (Fingerprint)
-
False Rejection Rate (FRR) %
FRR≤0.02% (Visible Light Facial Authentication), FRR≤0.01% (Fingerprint)
-
Biometric Algorithm
ZK Facial V4.0 (Standard), ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
-
Card Type
ID Card: 125 kHz (Optional), IC Card: 13.56 MHz (Optional)
-
Communication
Wi-Fi (IEEE 802.11b/g/n/ax) @ 2.4GHz; Wi-Fi 6 Enabled
USB: Type A 2.0 *1 (USB Drive Only) -
Standard Functions
ADMS, DST, Workcode, Up to 14-digit User ID, Record Query, Schedule Bell, Automatic Status Switch / Self-Service Report (Effective only under T&A rules), Multiple Authentication
Methods, HTTPS for cloud/Web access; SSH for backend maintenance; T9 Keyboard (Input), Online Firmware Upgrade, Tap-To-Unlock (ESC Button) -
Optional Functions
ID Card, IC Card, Backup Battery
-
Power Supply
DC 5V 2A
-
Operating Temperature
-5°C to 45°C
-
Operating Humidity
20% to 80% RH (Non-condensing)
-
Backup Battery (Optional)
2,000mAh (Lithium Battery)
Operating Hours: 2 Hours
Max.Standby Hours: 3.5 Hours
Estimated Charging Time: 5 Hours -
Dimensions
117.5 mm*116.6 mm*31.0 mm (L*W*H)
-
Gross Weight
0.45 Kg
-
Net Weight
0.24 Kg
-
Supported Software
Cloud-based Software: ZKBio Zlink by default (Supports Web Portal & Mobile App)
On-Premise Software: ZKBio Time (TA PUSH) -
Installation
Wall mount (Compatible with Asian Gang-Box/ Single Gang-Box)
Desk mount (Compatible with Rots-4 desktop stand) -
Certifications
ISO 9001, ISO14001, CE, FCC, RoHS
-
Order ID
SenseFace T1: TA01-VL06H-21
SenseFace T2: TA01-VL060H-21
