• Supports USB power supply.
• Supports Mifare card.
• Supports reading card numbers and writing data to a card’s specified sectors.
المواصفات الفنية (Specifications)
| OEC-W2D-M | ||||||||
| Physical | ||||||||
| Material | PC | |||||||
| Hardware Specification | ||||||||
| Weight | 0.17kg (with package), 0.058kg (net weight) | |||||||
| Mount Method | Desktop mount | |||||||
| Power Supply | Voltage: DC 5V (powered by USB), current ≤ 116mA | |||||||
| Operating Frequency | 13.56MHz | |||||||
| Reading Distance | IC card: ≤ 3cm | |||||||
| Operating Environment | Temperature: -30°C to 65°C, humidity: 10% to 90% | |||||||
| Dimensions (L x W x H) | 110mm*65mm*24mm | |||||||
| Interface | USB (plug and play, driver-free) | |||||||
| Basic Business | ||||||||
| Card Protocol | ISO 14443-A, ISO 14443-B | |||||||
| Reading Time | < 1s | |||||||
| Data Format | 10-digit decimal card number | |||||||
| Specification Index | ||||||||
| Application Scenario | Indoors | |||||||
