System

Main Processor

<!–{v.name}–>

Industrial-grade processor

Operating System

<!–{v.name}–>

Embedded Linux

Operating Interface

<!–{v.name}–>

Web, Local GUI

AI

AI by Recorder

<!–{v.name}–>

Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus

AI by Camera

<!–{v.name}–>

Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring

AcuPick AI by Camera + Recorder

<!–{v.name}–>

Max. 32-channel, 1 combined event per channel

Perimeter Protection

Perimeter Performance AI by Recorder (Number of Channels)

<!–{v.name}–>

Simultaneous mode: 32 channels, 10 IVS rules for each channel

Heterogeneous mode: 24 channels, 10 IVS rules for each channel

Refer to the information on video output for details on the mode

Perimeter Performance of AI by Camera (Number of Channels)

<!–{v.name}–>

All channels (64 targets/s)

Face Detection

Face Attributes

<!–{v.name}–>

Gender; age group; glasses; expressions; face mask; beard

Face Detection Performance of AI by Recorder (Number of Channels)

<!–{v.name}–>

Simultaneous mode: 8 channels (up to 12 face images/s each channel)

Heterogeneous mode: 5 channels (up to 12 face images/s each channel)

Refer to the information on video output for details on the mode

Face Detection Performance of AI by Camera (Number of Channels)

<!–{v.name}–>

32 channels

Face Recognition

Face Database Capacity

<!–{v.name}–>

Up to 40 face databases with 300,000 images, with a total capacity of 48 G.

Face Recognition Performance of AI by Recorder (Number of Channels)

<!–{v.name}–>

Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s

Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s

Refer to the information on video output for details on the mode

Face Recognition Performance of AI by Camera (Number of Channels)

<!–{v.name}–>

32 channels

SMD Plus

SMD Plus by Recorder

<!–{v.name}–>

32-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change

SMD Plus by Camera

<!–{v.name}–>

All channels (128 targets/s)

Video Metadata

Metadata Performance of AI by Recorder (Number of Channels)

<!–{v.name}–>

8 channels

Metadata Performance of AI by Camera (Number of Channels)

<!–{v.name}–>

32 channels

People Attributes

<!–{v.name}–>

9 human body attributes

Human Attributes

<!–{v.name}–>

Top color, top type, hat, bag, age, gender and umbrella

Motor Vehicle Attributes

<!–{v.name}–>

License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling,

Non-motor Vehicle Attributes

<!–{v.name}–>

Vehicle model, vehicle color, number of persons, helmet.

Vehicle License Plate Comparison

ANPR by Camera (Number of Channels)

<!–{v.name}–>

All channels (64 targets/s)

License Plate Database Capacity

<!–{v.name}–>

Blocklist and allowlist: 20,000

Audio and Video

Access Channel

<!–{v.name}–>

32 channels

Network Bandwidth

<!–{v.name}–>

AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing

AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing

Resolution

<!–{v.name}–>

32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF

Decoding Capability

<!–{v.name}–>

AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps；128-channel D1@30 fps

AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps； 80-channel D1@30 fps

Video Output

<!–{v.name}–>

2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720

Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports)

Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p

Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1–4)

Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p

Multi-screen Display

<!–{v.name}–>

Main screen: 1/4/8/9/16/25/36

Sub screen: 1/4/8/9/16/25/36

Third-party Camera Access

<!–{v.name}–>

ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha

Compression Standard

Video Compression

<!–{v.name}–>

Smart H.265+; H.265; Smart H.264+; H.264; MPEG4; MJPEG

Audio Compression

<!–{v.name}–>

G.711a; G.711u; PCM; G726

Network

Network Protocol

<!–{v.name}–>

HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI

Mobile Phone Access

<!–{v.name}–>

iOS; Android

Interoperability

<!–{v.name}–>

ONVIF (Profile S/profile T/Profile G); CGI; SDK

Browser

<!–{v.name}–>

Chrome

IE 9 or later

Firefox

Network Mode

<!–{v.name}–>

Multi-address mode, load balance, fault tolerance and other network port binding modes

Recording Playback

Multi-channel Playback

<!–{v.name}–>

Up to 16 channels

Record Mode

<!–{v.name}–>

Manual; alarm; motion detection; scheduled

Backup Method

<!–{v.name}–>

Portable hard drive, eSATA disk, burner, USB device and network

Playback Mode

<!–{v.name}–>

1. Play, pause, stop, fast forward, fast backward, rewind, play by frame

2. Full screen, backup (cut/file), partially enlarge, audio on/off

Storage

Disk Group

<!–{v.name}–>

Yes

RAID

<!–{v.name}–>

RAID 0/1/5/6/10

Hot Swapping

<!–{v.name}–>

Yes

Alarm

General Alarm

<!–{v.name}–>

Motion detection; video tampering; video loss; scene changing, PIR alarm, IPC external alarm

Anomaly Alarm

<!–{v.name}–>

Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan

Intelligent Alarm

<!–{v.name}–>

Face detection; face recognition; perimeter protection (intrusion and tripwire); SMD Plus alarms; ANPR; people counting; stereo analysis; crowd distribution; heat map

Alarm Linkage

<!–{v.name}–>

Record; snapshot; IPC external alarm output; buzzer; log, preset; email

Port

Audio Input

<!–{v.name}–>

1-channel RCA

Audio Output

<!–{v.name}–>

2-channel RCA

Alarm Input

<!–{v.name}–>

16 channels

Alarm Output

<!–{v.name}–>

8 channels

Disk Interface

<!–{v.name}–>

8 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.

eSATA

<!–{v.name}–>

1

RS-232

<!–{v.name}–>

1

RS-485

<!–{v.name}–>

1 × A/B

USB

<!–{v.name}–>

4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)

HDMI

<!–{v.name}–>

4

VGA

<!–{v.name}–>

2

Network Port

<!–{v.name}–>

2 (10/100/1000/2500 Mbps Ethernet port, RJ-45)

General

Power Supply

<!–{v.name}–>

100–240 VAC, 50/60 Hz

Redundant Power

<!–{v.name}–>

Yes

Power Consumption

<!–{v.name}–>

<18 W (without HDD)

Net Weight

<!–{v.name}–>

8.14 kg (17.95 lb) (without HDD）

Gross Weight

<!–{v.name}–>

12.24 kg (26.98 lb) (without HDD)

Product Dimensions

<!–{v.name}–>

444.0 mm × 476.0 mm x 95.0 mm (17.48″ × 18.74″ × 3.74″) (W × D × H)

Packaging Dimensions

<!–{v.name}–>

571.0 mm × 618.0 mm × 219.0 mm (22.48″ × 24.33″ × 8.62″)(W × D × H)

Operating Temperature

<!–{v.name}–>

–10 °C to +55 °C (14 °F to +131 °F)

Storage Temperature

<!–{v.name}–>

0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity

<!–{v.name}–>

10%–93% (RH), non-condensing

Installation

<!–{v.name}–>

Rack or desktop

Certifications

<!–{v.name}–>

FCC: 47 CFR FCC Part15, SubpartB, Class A

CE-EMC: EN 55032:2020, Class A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2020; EN 50130-4:2011+A1:2014

CE-LVD: EN 62368-1:2014+A11:2017
