NVR501-04B-P4-A

NVR501-04B-P4-A

0,00 EGP

10 متوفر في المخزون

SKU: NVR501-04B-P4-A

• Support Ultra 265/H.265/H.264 video formats
• 4-channel input
• Plug & Play with 4 independent PoE network interfaces
• Support HDMI and VGA simultaneous output
• Up to 16 Megapixels resolution recording
• ANR technology to enhance the storage reliability when the network is disconnected
• Support cloud upgrade

المواصفات الفنية (Specifications)

 NVR501-04B-P4-A
Decoding
Decoding FormatUltra 265, H.265, H.264
Decoding CapabilityUltra 265/H.265: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30
H.264: 2 x 16MP(4800*2688)@30, 2 x 12MP@30, 2 x 4K@30, 4 x 5MP@30
Audio CompressionG.711A, G.711U
Network
Incoming Bandwidth80 Mbps
Outgoing Bandwidth64 Mbps
Max Users Can Be Added32
Remote Users128
ProtocolsTCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6
Browser (Plugin)Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above)
Video/Audio Input
IP Video Input4-ch
RCA Audio Input1-ch
Video/Audio Output
HDMI OutputHDMI:4K(3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
VGA OutputVGA:1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
RCA Audio Output1-ch
Liveview Display1/4
Corridor Mode Screen3/4
Two-way Audio
Two-way Audio1-ch, RCA (Using the audio input and output)
Snapshot
FTP/Schedule/Event Snapshot4-ch snapshot, up to D1 resolution
Recording
Recording Resolution16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF
Smart Function
Smart by IPCTotal 4-ch(Face Detection, SIP, UMD)
VCA SearchMotor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map
Alarm
General AlarmDefocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
Alert AlarmIP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
GUI Language
GUI Language38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian
Hard Disk
SATA1 SATA Interface
CapacityUp to 24 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size, The environment temperature for use should not exceed 40°C)
External Interface
Network Interface1 RJ45 10 M/100 M self-adaptive Ethernet Interface
USBRear panel: 1 × USB2.0, 1 × USB3.0
RS485N/A
RS232N/A
Alarm In4-ch
Alarm Out1-ch
Power SupplyDC 48 V/1.35 A
PoE
Max PowerMax 30 W for single port, Max 50 W in total
Supported StandardIEEE 802.3at, IEEE 802.3af
Working Environment
Working Temperature-10 ℃ to 55 ℃ (14 ℉ to 131 ℉)
Working Humidity≤ 90% RH (non-condensing)
Power Consumption (without HDD)≤ 10W
Dimensions
Weight (without HDD)≤ 1.1Kg (2.43lb)
Dimensions260mm × 222mm × 47mm (10.2"×8.7"×1.8")
Certification
CertificationCE, FCC, UL, RoHS, WEEE
CEEN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035
FCCPart15 Subpart B
