المواصفات الفنية (Specifications)
| NVR-104S3-P4 | NVR-108S3-P8 | |||||||
| Decoding | ||||||||
| Decoding Format | Ultra 265, H.265, H.264 | |||||||
| Decoding Capability | 2 x 6MP@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080P@30 | 2 x 6MP@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30 | ||||||
| Decoding Capability Description | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width | |||||||
| Audio Compression | G.711A, G.711U | |||||||
| Network | ||||||||
| Incoming Bandwidth | 64 Mbps | |||||||
| Outgoing Bandwidth | 48 Mbps | |||||||
| Remote Users | 128 | |||||||
| Protocols | TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4 | |||||||
| Browser (Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ | |||||||
| Video/Audio Input | ||||||||
| IP Video Input | 4-ch | 8-ch | ||||||
| Video/Audio Output | ||||||||
| HDMI Output | 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | |||||||
| VGA Output | 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | |||||||
| 3.5mm Audio Output | 1-ch | |||||||
| Liveview Display | 1/4 | 1/4/6/8/9 | ||||||
| Corridor Mode Screen | 3/4 | 3/4/5/7/9 | ||||||
| Recording | ||||||||
| Recording Resolution | 6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF | |||||||
| Synchronous Playback in Local | 4-ch | 8-ch | ||||||
| Smart Function | ||||||||
| VCA Detection by IPC | SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD) | |||||||
| VCA Search | Behavior Search | |||||||
| Smart by IPC | Total 4-ch(SIP supports channel 1-4, Alarm only, no image) | |||||||
| GUI Language | ||||||||
| GUI Language | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian | |||||||
| Hard Disk | ||||||||
| SATA | 1 SATA Interface | |||||||
| Capacity | Up to 6 TB for each HDD | |||||||
| External Interface | ||||||||
| Network Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet Interface | |||||||
| USB | Rear panel: 2 × USB2.0 | |||||||
| Power Supply | DC 48 V/1.35 A | DC 52 V/1.8 A | ||||||
| PoE | ||||||||
| PoE Interface | 4 RJ45 10 M/100 M self-adaptive Ethernet Interface | 8 RJ45 10 M/100 M self-adaptive Ethernet Interface | ||||||
| Max Power | Max 30 W for single port, Max 50 W in total | Max 30 W for single port, Max 75 W in total | ||||||
| Supported Standard | IEEE 802.3at, IEEE 802.3af | |||||||
| Working Environment | ||||||||
| Working Temperature | -10 ℃ to 55 ℃ (14 ℉ to 131 ℉) | |||||||
| Working Humidity | ≤ 90% RH (non-condensing) | |||||||
| Power Consumption (without HDD) | ≤ 9W | |||||||
| Dimensions | ||||||||
| Weight (without HDD) | ≤ 1.0Kg (2.20lb) | |||||||
| Dimensions | 190mm × 195mm × 42mm (7.5"×7.7"×1.6") | |||||||
| Certification | ||||||||
| Certification | CE; FCC; RoHS; WEEE | |||||||
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 | |||||||
| FCC | Part15 Subpart B | |||||||
