• Supports IEEE802.3 and IEEE802.3u standards.
• Supports 10/100Mbps or 10/100/1000Mbps self-adaptive Ethernet port.
• Supports auto MDI/MDIX.
• Supports IEEE802.3 flow control for full-duplex mode and backpressure for half-duplex mode.
المواصفات الفنية (Specifications)
| NSW1010-8GT-IN | ||||||||
| Hardware Specification | ||||||||
| Ports Type | 8 x 10/100/1000Mbps port (RJ45) | |||||||
| Network Media | 10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) 1000Base-TX: Cat5e or higher UTP/STP (≤100m) | |||||||
| Switching capacity | 16 Gbps | |||||||
| Forwarding performance | 11.9Mpps | |||||||
| MAC | 2K | |||||||
| Jumbo Frame | 15K | |||||||
| Transfer Mode | Store-and-forward | |||||||
| Dimensions (W×D×H) | Product: 145*60*21.5mm Packaging: 146*88*50mm | |||||||
| Carton Information | Carton dimensions: 530*475*315mm Carton quantity: 100PCS Carton weight: 17.6kg | |||||||
| Weight | Product: 0.111kg Packaging: 0.166kg | |||||||
| Mount Method | Desktop mount, wall mount | |||||||
| Cooling Fans | 0 | |||||||
| Operating humidity | 10%～90% (non-condensing) | |||||||
| Storage Temperature | -20°C to 70°C | |||||||
| Storage Humidity | 5% to 90% RH, noncondensing | |||||||
