Camera

Image Sensor

<!–{v.name}–>

1/2.7″ CMOS

Max. Resolution

<!–{v.name}–>

3840 (H) × 2160 (V)

ROM

<!–{v.name}–>

128 MB

RAM

<!–{v.name}–>

256 MB

Scanning System

<!–{v.name}–>

Progressive

Electronic Shutter Speed

<!–{v.name}–>

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

<!–{v.name}–>

0.008 lux@F1.6 (Color, 30 IRE);

0.0008 lux@F1.6 (B/W, 30 IRE);

0 lux (Illuminator on)

S/N Ratio

<!–{v.name}–>

＞56 dB

Illumination Distance

<!–{v.name}–>

Up to 30 m (98.43 ft) (IR)

Up to 30 m (98.43 ft) (Warm light)

Illuminator On/Off Control

<!–{v.name}–>

Auto;Manual

Illuminator Number

<!–{v.name}–>

3 (IR LED); 4 (Warm light)

Angle Adjustment

<!–{v.name}–>

Pan: 0°–355°;

Tilt: 0°–65°;

Rotation: 0°–355°

Lens

Lens Type

<!–{v.name}–>

Fixed-focal

Lens Mount

<!–{v.name}–>

M12

Focal Length

<!–{v.name}–>

2.8 mm; 3.6 mm

Max. Aperture

<!–{v.name}–>

F1.6

Field of View

<!–{v.name}–>

2.8 mm: H: 110°; V: 58°; D: 132°3.6 mm: H: 86°; V: 49°; D: 100°

Iris Control

<!–{v.name}–>

Fixed

Close Focus Distance

<!–{v.name}–>

2.8 mm: 1.5 m (4.92 ft)3.6 mm: 1.9 m (6.23 ft)

DORI Distance

<!–{v.name}–>

Lens

<!–{v2}–>

Detect

<!–{v2}–>

Observe

<!–{v2}–>

Recognize

<!–{v2}–>

Identify

<!–{v2}–>

2.8 mm

<!–{v2}–>

84.8 m( 278.22 ft)

<!–{v2}–>

33.9 m( 111.22 ft)

<!–{v2}–>

17.0 m( 55.77 ft)

<!–{v2}–>

8.5 m

( 27.89 ft)

<!–{v2}–>

3.6 mm

<!–{v2}–>

98.7 m( 323.82 ft)

<!–{v2}–>

39.5 m( 129.59 ft)

<!–{v2}–>

19.7 m( 64.63 ft)

<!–{v2}–>

9.9 m

( 32.48 ft)

<!–{v2}–>

Intelligence

IVS (Perimeter Protection)

<!–{v.name}–>

Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)

SMD

<!–{v.name}–>

SMD Plus

Smart Search

<!–{v.name}–>

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

<!–{v.name}–>

H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec

<!–{v.name}–>

Smart H.265+; Smart H.264+

Video Frame Rate

<!–{v.name}–>

Main stream: 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps)

sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability

<!–{v.name}–>

2 streams

Resolution

<!–{v.name}–>

8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2880 × 1620); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

<!–{v.name}–>

VBR;CBR

Video Bit Rate

<!–{v.name}–>

H.264: 32 kbps–8192 kbps;

H.265: 12 kbps–8192 kbps

Day/Night

<!–{v.name}–>

Auto(ICR)/Color/B/W

BLC

<!–{v.name}–>

Yes

HLC

<!–{v.name}–>

Yes

WDR

<!–{v.name}–>

120 dB

White Balance

<!–{v.name}–>

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

<!–{v.name}–>

Auto/Manual

Noise Reduction

<!–{v.name}–>

3D NR

Motion Detection

<!–{v.name}–>

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

<!–{v.name}–>

Yes (4 areas)

Smart Illumination

<!–{v.name}–>

Yes

Smart Dual Light

<!–{v.name}–>

Yes

Image Rotation

<!–{v.name}–>

0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)

Mirror

<!–{v.name}–>

Yes

Privacy Masking

<!–{v.name}–>

4 areas

Audio

Built-in MIC

<!–{v.name}–>

Yes, built-in Mic

Audio Compression

<!–{v.name}–>

G.711a; G.711Mu; PCM; G.726

Alarm

Alarm Event

<!–{v.name}–>

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception

Network

Network Port

<!–{v.name}–>

RJ-45 (10/100 Base-T)

SDK and API

<!–{v.name}–>

Yes

Network Protocol

<!–{v.name}–>

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P

Interoperability

<!–{v.name}–>

ONVIF (Profile S & Profile G & Profile T); CGI

User/Host

<!–{v.name}–>

20 (Total bandwidth: 48 M)

Storage

<!–{v.name}–>

FTP; SFTP; Micro SD card (support max. 256 GB); NAS

Browser

<!–{v.name}–>

IE; Chrome; Firefox

Management Software

<!–{v.name}–>

Smart PSS Lite; DSS; DMSS; DoLynk Care

Mobile Client

<!–{v.name}–>

iOS;Android

Cyber Security

<!–{v.name}–>

Video encryption;Firmware encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade

Certification

Certifications

<!–{v.name}–>

CE-LVD: EN62368-1;

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power

Power Supply

<!–{v.name}–>

12 VDC/PoE (802.3af)

Power Consumption

<!–{v.name}–>

Basic: 2.6 W (12 VDC), 3.3 W (PoE);

Max.: 6.9 W (12 VDC), 8.3 W (PoE) (H.265 + intelligence on+ WDR + illuminator intensity)

Environment

Operating Temperature

<!–{v.name}–>

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

<!–{v.name}–>

≤95%(RH), non-condensing

Storage Temperature

<!–{v.name}–>

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

<!–{v.name}–>

≤95%(RH), non-condensing

Protection

<!–{v.name}–>

IP67; IK10

Structure

Casing Material

<!–{v.name}–>

Metal

Product Dimensions

<!–{v.name}–>

81.0 mm × Φ109.9 mm (3.19″ × Φ4.33″)

Net Weight

<!–{v.name}–>

0.36 kg (0.79 lb)

Gross Weight

<!–{v.name}–>

0.51 kg (1.12 lb)
