Parameters

• System

• Operation System

  Android 9.0

• CPU

  64bit Eight Core Customized Computer Vision CPU

• Storage

  2GB LPDDR3 16GB eMMC

• SDK

  Android LCDP, PUSH SDK

• Basic

• Communication

  TCP / IP, Wi-Fi, Bluetooth, USB

• Display

  8 inch TFT LCD Color Screen

• Screen Type

  Capacitive Touch Screen

• Resolution

  800*1280

• Camera

  2MP Binocular Camera

• QR Code (optional)

  Dynamic QR codes on the ZKBio CVSecurity mobile application QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects

• Card Type

  Dual-frequency (125kHz and 13.56MHz)
  card module (standard)
  Multi-tech Card Module (optional)
  ISO14443A / B & ISO15693 & HID Prox

• Interface

• USB

  1 USB 3.0, 1 USB 2.0, 1 Micro USB

• Power Adapter

  12V 3A

• Ethernet

  RJ45, 1000M

• RS232

  1

• RS485

  1

• Wiegand

  1 input, 1 output

• Auxiliary input

  1

• Sensor

  1

• Exit Button

  1

• Lock

  1

• Alarm

  1

• Bell

  1

• Power out

  1, 12V

• Reset Button

  1

• Performance

• Protective level

  IP66 without Fingerprint / QR Code Reader
  IP65 with Fingerprint / QR Code Reader
  IK04

• Card reading distance

  1cm–5cm

• Face Recognition Range

  Face-camera distance: Range 0.3 m to 1.2 m;
  Human height: 0.9 m to 2.4 m

• Face Verification Accuracy

  ≥99%

• Face Recognition Time

  < 1s

• Fingerprint Sensor Type(optional)

  Optical

• Fingerprint Comparison Time

  ≤0.5s

• Facial Recognition Method

  1:1, 1:N




• Facial Recognition Algorithm

  ZKFace 5.6.2

• Fingerprint Verification Method

  1:1, 1:N

• Fingerprint Recognition Algorithm

  ZKFinger 10.0

• Facial Recognition FAR

  0.01%

• Facial Recognition FRR

  1%

• Firmware

• User Capacity

  100,000

• Face Templates Capacity

  100,000

• Fingerprint Capacity (optional)

  30,000

• Card Capacity

  100,000

• Record Capacity

  1,000,000

• Standard Firmware Functions

  Push, Schedule Bell, Automatic Status Switch, Record Query, Access Levels, Groups, Holidays, DST, Duress Mode (Password & Fingerprint), Anti-Passback, Customization of Wallpaper & Screen Saver,Tamper Alarm

• Language

  English, Korean, Latin American, Indonesian, Vietnamese, traditional Chinese, Portuguese, Spanish, Farsi, Japanese, Russian and Thai

• Software

  ZKBio Time, ZKBio CVSecurity

• General

• Power Supply

  12V 3A; PoE (IEEE802.3af / at)

• Dimensions

  279.5mm*141mm*29mm(11in*5.55in*1.14in)

• Operating Temperature

  -10℃ to 50℃ (14°F to 122°F)

• Operating Humidity

  <90%RH

• Operating Environment

  Outdoor

• Gross Weight

  1.2kg

• Installation Method

  Wall-mounted or Turnstile top-mount bracket




• Certifications

  CE, FCC, ISO9001, ISO14001, IP66, IK04
