• High-Quality Hardware Design
• high performance
• 12Gbps SAS-3 technology provides superior performance experience
• High density
• The innovative enclosure with 589mm depth and 4U height that holds up to 24 disks, is space-saving
• Redundant power supplies
• The hot-swappable power supply is designed in redundancy and load balancing mode. Automatic power switching in case of failure and online replacement of failed power supply are supported.
• Power protection
• Disk powered on sequentially during system startup, protection from impulse current.
• Multistage fan speed and energy saving
• Fans with multistage speed are configured in the hot-swappable frame in redundancy mode. System power consumption can be balanced intelligently with heat dissipation calculation to ensure low power consumption and stable operation of the system.
المواصفات الفنية (Specifications)
| DE3124-V2 | ||||||||
| Module | ||||||||
| Controller number | 2 | |||||||
| Power Consumption | 270W (fully loaded) | |||||||
| Power Supply | 100V – 127V/200V – 240V AC;60Hz/50Hz | |||||||
| Weight | Fully loaded:< 40kg | |||||||
| Dimension | 482.0mm × 589.0mm × 175.0 mm | |||||||
| Authentication certificate | CE, FCC, CB,RoHS, WEEE | |||||||
| Operating temperature | 5°C ~ 40°C / 41°F ~ 104°F | |||||||
| Interface | ||||||||
| HDD slot | 24 | |||||||
| Serial port | 2 | |||||||
| Back-end Expansion Interface | 4-port 4*12Gbps Mini SAS HD(Primary) 4-port 2*12Gbps Mini SAS HD(Backup) | |||||||
