Port

Wireless Zone

<!–{v.name}–>

150 channels wireless peripherals (6 sirens, 64 PIR cameras, 64 keyfobs, 8 keypads and 4 repeaters)

Network Mode

<!–{v.name}–>

Europe: Supports installation of dual SIM cards. Only one card can be enabled at a time. Also, multiple frequency bands are supported for the SIM cards (GSM: 900/1, 800 MHz, WCDMA: B1/B8, LTE-FDD: B1/B3/B7/B8/B20/B28A, LTE-TDD:B38/B40/B41).₩USA: Supports installation of dual SIM cards. Only one card can be enabled at a time. Also, multiple frequency bands are supported for the SIM cards (GSM: 850/900/1800/1900 MHz, WCDMA:B1/B2/B4/B5/B8, LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B28, LTE-TDD: B40)

Network Port

<!–{v.name}–>

1 RJ-45, 10 Mbps/100 Mbps Ethernet port.

Storage Battery

<!–{v.name}–>

One built-in 4,750 mah rechargeable lithium battery.

Video & Audio

Video Input

<!–{v.name}–>

8-ch IPC, which only supports the upload of alarm videos.

Audio Output

<!–{v.name}–>

1 channel

Volume Control

<!–{v.name}–>

Yes

Voice Broadcast

<!–{v.name}–>

Telephone and local speaker

Function

Indicator Light

<!–{v.name}–>

The indicator indicates the status of alarms, arming and disarming, the network connection and device failure.

Button

<!–{v.name}–>

Includes a reset button, voltage button and AP switch button.

SMS

<!–{v.name}–>

Yes (up to 5 phone numbers)

Phone Call

<!–{v.name}–>

Yes (up to 5 phone numbers)

Video Linkage

<!–{v.name}–>

Yes

Offline Cache

<!–{v.name}–>

Stores up to 50 alarm messages.

Arm and Disarm

<!–{v.name}–>

App, keyboard, remote control, card, scheduled arming and disarming.

Remote Update

<!–{v.name}–>

Cloud update

Low Battery Detection

<!–{v.name}–>

Yes

Tamper

<!–{v.name}–>

Yes

User Management

<!–{v.name}–>

Functions can be shared by the app users. These include 1 installer, 1 administrator and 31 general users.

Logs

<!–{v.name}–>

Up to 5, 000 entries

Transmission Protocol

<!–{v.name}–>

SIA, SoftGuard

Wireless

Carrier Frequency

<!–{v.name}–>

433.1–434.6 MHz

Communication Mechanism

<!–{v.name}–>

Two-way

Communication Distance

<!–{v.name}–>

Up to 1,400 m (4593.18 ft) in an open space.

Encryption Mode

<!–{v.name}–>

AES128

Frequency Hopping

<!–{v.name}–>

Yes

Wi-Fi

<!–{v.name}–>

2.4 G

General

Language

<!–{v.name}–>

Up to 7 languages are supported for SMS: English, Spanish (Latin America), French, Italian, Arabic, Turkish, and Danish. It is set as English by default. The alarm voice message feature and local speaker only support English.

Power Supply

<!–{v.name}–>

100–240 VAC, 50/60 Hz

Standby Time

<!–{v.name}–>

The battery lasts up to 12 hours when it is fully charged and is within the following conditions: It is connected to the Wi-Fi, its ID is connected to the alarm receiving center, the heartbeat interval is 1,800 seconds, and it is connected to 8 peripherals and the cloud.

Power Consumption

<!–{v.name}–>

≤12 W

Operating Temperature

<!–{v.name}–>

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

<!–{v.name}–>

10%–90% (RH)

Product Dimensions

<!–{v.name}–>

174.8 mm × 174.8 mm × 38.3 mm (6.88” × 6.88” × 1.51”) (L × W × H)

Net Weight

<!–{v.name}–>

510 g (1.12 lb)

Gross Weight

<!–{v.name}–>

860 g (1.90 lb)

Installation

<!–{v.name}–>

Supports wall mount and desktop mount installation.

Casing Material

<!–{v.name}–>

PC + ABS

Certifications

<!–{v.name}–>

CE

Anti-corrosion Level

<!–{v.name}–>

Basic Protection

Storage Temperature

<!–{v.name}–>

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Humidity

<!–{v.name}–>

10%–90% (RH)

Packaging Dimensions

<!–{v.name}–>

254 mm × 211 mm × 61 mm (10.00” × 8.31” × 2.40”) (L × W × H), standalone in the inner box

524 mm × 508 mm × 442 mm (20.63” × 20.00” × 17.40“) (L × W × H), protective case
